    Roll Electrode Film Battery Coating Machine Slot Die Three Drying Chamber

    Ask Lasest Price
    Brand Name : TICO
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 20 sets per month
    Delivery Time : 15~20 working days
    Model Number : STC-TMJ-500F3
    • Product Details
    • Company Profile

    Roll Electrode Film Battery Coating Machine Slot Die Three Drying Chamber

    Slot Die Roll to Roll Electrode Film Coating Machine with Three Drying Chamber for Battery Production

    Product Introduction

    This machine is applied in Lithium-ion battery electrode coating process of cathode & anode. The slot extrusion coating die is used for non-contact coating to substrate, which can realize the continuous, intermittence, stripe film coating and etc. This machine owns the higher coating precise, consistency and stability, it also can be applied in the others slurry and substrate film coating.


    Features


    Extrusion coating process, high precise.
    The temperature of each drying oven can be controlled independently.
    The qty and dimension of drying oven can be customized according to requirement.
    Modular design, easier to install.
    Wider roller, it is the ideal of machine for small pilot line.
    Continuous, intermittence film coating model can be changed freely.


    Technical Parameter

    ModelSTC-TMJ-500F3
    Substrate thicknessAluminum foil: 0.010~0.030mm
    Copper foil: 0.006~0.030mm
    Substrate widthAluminum foil: 100~350mm
    Copper foil: 100~350mm
    Max. wet thickness of coating80~40µm (on the basis of satisfying the slurry viscosity requirements)
    Max width of coating330mm
    Max width of coating roller500mm
    Mechanical conveying speed0.5~7m/min
    Coating speed0.5~1.2m/min (it various based on different slurries)
    Oven length3 oven×1.5m/oven, total 4.5m. Oven qty can be available.
    Voltage380V
    Drying formHot air dryingHot air circulation (upper and lower air supply
    Heating methodElectric heating 4.8KW×3 sections, total 14.4KW
    Oven materialOven is made of stainless steel, both internally and externally
    Oven temperatureRT~150℃, adjustable. Accuracy, <±5℃
    Coating accuracyAccuracy error of dry thicknessSingle-sided anode: ±2.0µm, cathode: ±2.0µm
    Alignment error of two sides coating≤±1.0mm
    Average length error≤±1.0mm
    Average width error≤±1.0mm


    Warranty

    1 year warranty with lifetime support. Man-made damage is not included.

    FAQ

    1. Are you a manufacturer?

    A: Yes, our factory is located in Shenzhen, China.
    We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.


    2. Do you accept customized product?
    A: Yes. Most of our products can be customized to meet different requirements.


    3. Will you provide test video before dispatch?
    A: Yes, we take test video for every equipment before dispatch, which will display how to use it.


    4. Can you offer overseas installation service?
    A: Yes, we can dispatch professional engineer for on-site installation service.
